通过Helm开启APISIX Prometheus指标并验证暴露服务
一、开启 prometheus 指标收集
1.1 通过 helm 方式修改
说明：可以参考前面章节完成apisix部署
helm install apisix apisix/apisix \
--set apisix.ssl.enabled=true \
--set service.type=LoadBalancer \
--set ingress-controller.enabled=true \
--namespace ingress-apisix \
--set dashboard.enabled=true \
--set ingress-controller.config.apisix.serviceNamespace=ingress-apisix \
--set timezone=Asia/Shanghai \
--set apisix.prometheus.enabled=true
1.2 修改 values.yaml 文件
[root@master01 ~]# cd /root/16/apisix/
[root@master01 apisix]# vim values.yaml
#修改第472行内容
472 enabled: true
修改后完整配置文件
[root@master01 apisix]# egrep -v "#|^$" values.yaml
global:
imagePullSecrets: []
image:
repository: registry.cn-hangzhou.aliyuncs.com/abroad_images/apisix
pullPolicy: IfNotPresent
tag: 3.8.0-debian
useDaemonSet: false
replicaCount: 1
priorityClassName: ""
podAnnotations: {}
podSecurityContext: {}
securityContext: {}
podDisruptionBudget:
enabled: false
minAvailable: 90%
maxUnavailable: 1
resources: {}
hostNetwork: false
nodeSelector: {}
tolerations: []
affinity: {}
timezone: "Asia/Shanghai"
extraEnvVars: []
updateStrategy: {}
extraDeploy: []
extraVolumes: []
extraVolumeMounts: []
extraInitContainers: []
extraContainers: []
initContainer:
image: registry.cn-hangzhou.aliyuncs.com/abroad_images/busybox
tag: 1.28
autoscaling:
enabled: false
version: v2
minReplicas: 1
maxReplicas: 100
targetCPUUtilizationPercentage: 80
targetMemoryUtilizationPercentage: 80
nameOverride: ""
fullnameOverride: ""
serviceAccount:
create: false
annotations: {}
name: ""
rbac:
create: false
service:
type: LoadBalancer
externalTrafficPolicy: Cluster
externalIPs: []
http:
enabled: true
servicePort: 80
containerPort: 9080
additionalContainerPorts: []
tls:
servicePort: 443
stream:
enabled: false
tcp: []
udp: []
labelsOverride: {}
ingress:
enabled: false
servicePort:
annotations: {}
hosts:
- host: apisix.local
paths: []
tls: []
metrics:
serviceMonitor:
enabled: true
namespace: "ingress-apisix"
name: ""
interval: 15s
labels: {}
annotations: {}
apisix:
enableIPv6: true
enableServerTokens: true
setIDFromPodUID: false
luaModuleHook:
enabled: false
luaPath: ""
hookPoint: ""
configMapRef:
name: ""
mounts:
- key: ""
path: ""
ssl:
enabled: true
containerPort: 9443
additionalContainerPorts: []
existingCASecret: ""
certCAFilename: ""
http2:
enabled: true
sslProtocols: "TLSv1.2 TLSv1.3"
fallbackSNI: ""
router:
http: radixtree_host_uri
fullCustomConfig:
enabled: false
config: {}
deployment:
mode: traditional
role: "traditional"
admin:
enabled: true
type: ClusterIP
externalIPs: []
ip: 0.0.0.0
port: 9180
servicePort: 9180
cors: true
credentials:
admin: <admin-api-key>
viewer: <viewer-api-key>
secretName: ""
allow:
ipList:
- 127.0.0.1/24
ingress:
enabled: false
annotations:
{}
hosts:
- host: apisix-admin.local
paths:
- "/apisix"
tls: []
nginx:
workerRlimitNofile: "20480"
workerConnections: "10620"
workerProcesses: auto
enableCPUAffinity: true
keepaliveTimeout: 60s
envs: []
logs:
enableAccessLog: true
accessLog: "/dev/stdout"
accessLogFormat: '$remote_addr - $remote_user [$time_local] $http_host \"$request\" $status $body_bytes_sent $request_time \"$http_referer\" \"$http_user_agent\" $upstream_addr $upstream_status $upstream_response_time \"$upstream_scheme://$upstream_host$upstream_uri\"'
accessLogFormatEscape: default
errorLog: "/dev/stderr"
errorLogLevel: "warn"
configurationSnippet:
main: |
httpStart: |
httpEnd: |
httpSrv: |
httpAdmin: |
stream: |
customLuaSharedDicts: []
discovery:
enabled: false
registry: {}
dns:
resolvers:
- 127.0.0.1
- 172.20.0.10
- 114.114.114.114
- 223.5.5.5
- 1.1.1.1
- 8.8.8.8
validity: 30
timeout: 5
vault:
enabled: false
host: ""
timeout: 10
token: ""
prefix: ""
prometheus:
enabled: true
path: /apisix/prometheus/metrics
metricPrefix: apisix_
containerPort: 9091
plugins: []
stream_plugins: []
pluginAttrs: {}
extPlugin:
enabled: false
cmd: ["/path/to/apisix-plugin-runner/runner", "run"]
wasm:
enabled: false
plugins: []
customPlugins:
enabled: false
luaPath: "/opts/custom_plugins/?.lua"
plugins:
- name: "plugin-name"
attrs: {}
configMap:
name: "configmap-name"
mounts:
- key: "the-file-name"
path: "mount-path"
externalEtcd:
host:
- http://etcd.host:2379
user: root
password: ""
existingSecret: ""
secretPasswordKey: "etcd-root-password"
etcd:
enabled: true
prefix: "/apisix"
timeout: 30
auth:
rbac:
create: false
rootPassword: ""
tls:
enabled: false
existingSecret: ""
certFilename: ""
certKeyFilename: ""
verify: true
sni: ""
service:
port: 2379
replicaCount: 3
dashboard:
enabled: true
config:
conf:
etcd:
endpoints:
- apisix-etcd:2379
prefix: "/apisix"
username: ~
password: ~
ingress-controller:
enabled: true
config:
apisix:
adminAPIVersion: "v3"
serviceNamespace: "ingress-apisix"
更新部署
[root@master01 apisix]#
helm upgrade apisix /root/16/apisix \
-n ingress-apisix \
-f values.yaml
验证
# apisix这个pod会自动重启
[root@master01 apisix]# kgp -n ingress-apisix | grep apisix-
apisix-944f5f799-8trxf 1/1 Running 0 77s
apisix-dashboard-766d98954c-s7m6n 1/1 Running 3 (4h59m ago) 5h
apisix-etcd-0 1/1 Running 0 4m31s
apisix-etcd-1 1/1 Running 0 5m54s
apisix-etcd-2 1/1 Running 0 7m4s
apisix-ingress-controller-559f594fc9-w8rhv 1/1 Running 0 5h
1.3 测试验证
#查看apisix-prometheus-metrics服务
[root@master01 apisix]# kubectl get svc -ningress-apisix |grep prometheus
apisix-prometheus-metrics ClusterIP <metrics-service-ip> <none> 9091/TCP 2m15s
#通过接口的方式验证
[root@master01 apisix]# curl <metrics-service-ip>:9091/apisix/prometheus/metrics
# HELP apisix_etcd_modify_indexes Etcd modify index for APISIX keys
# TYPE apisix_etcd_modify_indexes gauge
apisix_etcd_modify_indexes{key="consumers"} 57
apisix_etcd_modify_indexes{key="global_rules"} 0
apisix_etcd_modify_indexes{key="max_modify_index"} 128
apisix_etcd_modify_indexes{key="prev_index"} 145
apisix_etcd_modify_indexes{key="protos"} 0
apisix_etcd_modify_indexes{key="routes"} 128
apisix_etcd_modify_indexes{key="services"} 0
apisix_etcd_modify_indexes{key="ssls"} 37
apisix_etcd_modify_indexes{key="stream_routes"} 0
apisix_etcd_modify_indexes{key="upstreams"} 91
apisix_etcd_modify_indexes{key="x_etcd_index"} 147
...
...
1.4 创建 metrics 服务暴露
# 定义资源
[root@master01 16]# vim metrics-ing.yaml
apiVersion: apisix.apache.org/v2
kind: ApisixRoute
metadata:
name: metrics-route
namespace: ingress-apisix
spec:
http:
- backends:
- serviceName: apisix-prometheus-metrics
servicePort: 9091
match:
hosts:
- metrics.example.com
paths:
- /apisix/prometheus/metrics
name: metrics-route
# 应用
[root@master01 16]# kaf metrics-ing.yaml
# 查看
[root@master01 16]# kg -f metrics-ing.yaml
NAME HOSTS URIS AGE
metrics-route ["metrics.example.com"] ["/apisix/prometheus/metrics"] 32s
测试验证：
[root@master01 16]# curl metrics.example.com/apisix/prometheus/metrics
# HELP apisix_etcd_modify_indexes Etcd modify index for APISIX keys
# TYPE apisix_etcd_modify_indexes gauge
apisix_etcd_modify_indexes{key="consumers"} 57
apisix_etcd_modify_indexes{key="global_rules"} 0
apisix_etcd_modify_indexes{key="max_modify_index"} 149
apisix_etcd_modify_indexes{key="prev_index"} 145
apisix_etcd_modify_indexes{key="protos"} 0
apisix_etcd_modify_indexes{key="routes"} 149
apisix_etcd_modify_indexes{key="services"} 0
apisix_etcd_modify_indexes{key="ssls"} 37
apisix_etcd_modify_indexes{key="stream_routes"} 0
apisix_etcd_modify_indexes{key="upstreams"} 148
apisix_etcd_modify_indexes{key="x_etcd_index"} 149
...
...
二、配置 Prometheus 数据采集
将该 URI 地址添加到 Prometheus 中来提取指标数据，配置示例如下：
# 添加如下内容
########## apisix 监控配置 ##########
- job_name: "apisix"
scrape_interval: 15s #该值会跟 Prometheus QL 中 rate 函数的时间范围有关系，rate 函数中的时间范围应该至少两倍于该值。
metrics_path: "/apisix/prometheus/metrics"
static_configs:
- targets: [metrics.example.com]
# 完整配置文件
[root@master01 ~]# cd /root/7
[root@master01 7]# cat prometheus-config.yaml
apiVersion: v1
kind: ConfigMap
metadata:
name: prometheus-config
namespace: monitor
data:
prometheus.yml: |
global:
scrape_interval: 15s
evaluation_interval: 15s
external_labels:
cluster: "kubernetes"
############ 添加配置 Aertmanager 服务器地址 ###################
alerting:
alertmanagers:
- static_configs:
- targets: ["alertmanager:9093"]
############ 数据采集job ###################
scrape_configs:
########## prometheus 监控配置 ##########
- job_name: prometheus
static_configs:
- targets: ['127.0.0.1:9090']
labels:
instance: prometheus
########## apisix 监控配置 ##########
- job_name: "apisix"
scrape_interval: 15s
metrics_path: "/apisix/prometheus/metrics"
static_configs:
- targets: [metrics.example.com]
########## minio 监控配置 ##########
- job_name: minio-job
bearer_token: <prometheus-bearer-token>
metrics_path: /minio/v2/metrics/cluster
scheme: http
static_configs:
- targets: [s3.example.com]
########## kube-apiserver 监控配置 ##########
- job_name: kube-apiserver
kubernetes_sd_configs:
- role: endpoints
scheme: https
tls_config:
ca_file: /var/run/secrets/kubernetes.io/serviceaccount/ca.crt
bearer_token_file: /var/run/secrets/kubernetes.io/serviceaccount/token
relabel_configs:
- source_labels: [__meta_kubernetes_namespace, __meta_kubernetes_service_name]
action: keep
regex: default;kubernetes
- source_labels: [__meta_kubernetes_endpoints_name]
action: replace
target_label: endpoint
- source_labels: [__meta_kubernetes_pod_name]
action: replace
target_label: pod
- source_labels: [__meta_kubernetes_service_name]
action: replace
target_label: service
- source_labels: [__meta_kubernetes_namespace]
action: replace
target_label: namespace
########## kube-controller-manager 监控配置 ##########
- job_name: 'kube-controller-manager'
# 使用 Kubernetes Pod 发现机制
kubernetes_sd_configs:
- role: pod
# 强制使用 HTTPS 协议
scheme: https
# TLS 配置（测试环境跳过验证）
tls_config:
insecure_skip_verify: true
# 使用 ServiceAccount 的 Token 认证
bearer_token_file: /var/run/secrets/kubernetes.io/serviceaccount/token
relabel_configs:
# 保留标签为 component=kube-controller-manager 的 Pod
- source_labels: [__meta_kubernetes_pod_label_component]
regex: kube-controller-manager
action: keep
# 重写目标地址为 Pod IP + 10257 端口
- source_labels: [__meta_kubernetes_pod_ip]
regex: (.+)
target_label: __address__
replacement: "${1}:10257"
# 强制使用 HTTPS 协议（冗余但明确）
- source_labels: []
regex: .*
target_label: __scheme__
replacement: https
# 附加元数据标签
- source_labels: [__meta_kubernetes_endpoints_name]
action: replace
target_label: endpoint
- source_labels: [__meta_kubernetes_pod_name]
action: replace
target_label: pod
- source_labels: [__meta_kubernetes_service_name]
action: replace
target_label: service
- source_labels: [__meta_kubernetes_namespace]
action: replace
target_label: namespace
########## kube-scheduler 监控配置 ##########
- job_name: 'kube-scheduler'
kubernetes_sd_configs:
- role: pod
scheme: https
tls_config:
insecure_skip_verify: true
bearer_token_file: /var/run/secrets/kubernetes.io/serviceaccount/token
relabel_configs:
- source_labels: [__meta_kubernetes_pod_label_component]
regex: kube-scheduler
action: keep
- source_labels: [__meta_kubernetes_pod_ip]
regex: (.+)
target_label: __address__
replacement: "${1}:10259"
- source_labels: []
regex: .*
target_label: __scheme__
replacement: https
- source_labels: [__meta_kubernetes_endpoints_name]
action: replace
target_label: endpoint
- source_labels: [__meta_kubernetes_pod_name]
action: replace
target_label: pod
- source_labels: [__meta_kubernetes_service_name]
action: replace
target_label: service
- source_labels: [__meta_kubernetes_namespace]
action: replace
target_label: namespace
########## kube-state-metrics 监控配置 ##########
- job_name: kube-state-metrics
kubernetes_sd_configs:
- role: endpoints
relabel_configs:
- source_labels: [__meta_kubernetes_service_name]
regex: kube-state-metrics
action: keep
- source_labels: [__meta_kubernetes_pod_ip]
regex: (.+)
target_label: __address__
replacement: ${1}:8080
- source_labels: [__meta_kubernetes_endpoints_name]
action: replace
target_label: endpoint
- source_labels: [__meta_kubernetes_pod_name]
action: replace
target_label: pod
- source_labels: [__meta_kubernetes_service_name]
action: replace
target_label: service
- source_labels: [__meta_kubernetes_namespace]
action: replace
target_label: namespace
########## coredns 监控配置 ##########
- job_name: coredns
kubernetes_sd_configs:
- role: endpoints
relabel_configs:
- source_labels:
- __meta_kubernetes_service_label_k8s_app
regex: kube-dns
action: keep
- source_labels: [__meta_kubernetes_pod_ip]
regex: (.+)
target_label: __address__
replacement: ${1}:9153
- source_labels: [__meta_kubernetes_endpoints_name]
action: replace
target_label: endpoint
- source_labels: [__meta_kubernetes_pod_name]
action: replace
target_label: pod
- source_labels: [__meta_kubernetes_service_name]
action: replace
target_label: service
- source_labels: [__meta_kubernetes_namespace]
action: replace
target_label: namespace
########## etcd 监控配置 ##########
- job_name: etcd
kubernetes_sd_configs:
- role: pod
relabel_configs:
- source_labels:
- __meta_kubernetes_pod_label_component
regex: etcd
action: keep
- source_labels: [__meta_kubernetes_pod_ip]
regex: (.+)
target_label: __address__
replacement: ${1}:2381
- source_labels: [__meta_kubernetes_endpoints_name]
action: replace
target_label: endpoint
- source_labels: [__meta_kubernetes_pod_name]
action: replace
target_label: pod
- source_labels: [__meta_kubernetes_namespace]
action: replace
target_label: namespace
########## kubelet 监控配置 ##########
- job_name: kubelet
metrics_path: /metrics/cadvisor
scheme: https
tls_config:
insecure_skip_verify: true
bearer_token_file: /var/run/secrets/kubernetes.io/serviceaccount/token
kubernetes_sd_configs:
- role: node
relabel_configs:
- action: labelmap
regex: __meta_kubernetes_node_label_(.+)
- source_labels: [__meta_kubernetes_endpoints_name]
action: replace
target_label: endpoint
- source_labels: [__meta_kubernetes_pod_name]
action: replace
target_label: pod
- source_labels: [__meta_kubernetes_namespace]
action: replace
target_label: namespace
########## k8s-node 监控配置 ##########
- job_name: k8s-nodes
kubernetes_sd_configs:
- role: node
relabel_configs:
- source_labels: [__address__]
regex: '(.*):10250'
replacement: '${1}:9100'
target_label: __address__
action: replace
- action: labelmap
regex: __meta_kubernetes_node_label_(.+)
- source_labels: [__meta_kubernetes_endpoints_name]
action: replace
target_label: endpoint
- source_labels: [__meta_kubernetes_pod_name]
action: replace
target_label: pod
- source_labels: [__meta_kubernetes_namespace]
action: replace
target_label: namespace
########## DNS 监控配置 ##########
- job_name: "kubernetes-dns"
metrics_path: /probe # 不是metrics，是probe
params:
module: [dns_tcp] # 使用DNS TCP模块
static_configs:
- targets:
- kube-dns.kube-system:53 #不要省略端口号
- 8.8.4.4:53
- 8.8.8.8:53
- 223.5.5.5:53
relabel_configs:
- source_labels: [__address__]
target_label: __param_target
- source_labels: [__param_target]
target_label: instance
- target_label: __address__
replacement: blackbox-exporter.monitor:9115 # 服务地址，和上面的 Service 定义保持一致
########## ICMP 监控配置 ##########
- job_name: icmp-status
metrics_path: /probe
params:
module: [icmp]
static_configs:
- targets:
- <node-ip-1>
labels:
group: icmp
relabel_configs:
- source_labels: [__address__]
target_label: __param_target
- source_labels: [__param_target]
target_label: instance
- target_label: __address__
replacement: blackbox-exporter.monitor:9115
########## HTTP 监控配置 ##########
- job_name: 'kubernetes-services'
metrics_path: /probe
params:
module: ## 使用HTTP_GET_2xx与HTTP_GET_3XX模块
- "http_get_2xx"
- "http_get_3xx"
kubernetes_sd_configs: ## 使用Kubernetes动态服务发现,且使用Service类型的发现
- role: service
relabel_configs: ## 设置只监测Kubernetes Service中Annotation里配置了注解prometheus.io/http_probe: true的service
- action: keep
source_labels: [__meta_kubernetes_service_annotation_prometheus_io_http_probe]
regex: "true"
- action: replace
source_labels:
- "__meta_kubernetes_service_name"
- "__meta_kubernetes_namespace"
- "__meta_kubernetes_service_annotation_prometheus_io_http_probe_port"
- "__meta_kubernetes_service_annotation_prometheus_io_http_probe_path"
target_label: __param_target
regex: (.+);(.+);(.+);(.+)
replacement: $1.$2:$3$4
- target_label: __address__
replacement: blackbox-exporter.monitor:9115 ## BlackBox Exporter 的 Service 地址
- source_labels: [__param_target]
target_label: instance
- action: labelmap
regex: __meta_kubernetes_service_label_(.+)
- source_labels: [__meta_kubernetes_namespace]
target_label: kubernetes_namespace
- source_labels: [__meta_kubernetes_service_name]
target_label: kubernetes_name
########## TCP 监控配置 ##########
- job_name: "service-tcp-probe"
scrape_interval: 1m
metrics_path: /probe
# 使用blackbox exporter配置文件的tcp_connect的探针
params:
module: [tcp_connect]
kubernetes_sd_configs:
- role: service
relabel_configs:
# 保留prometheus.io/scrape: "true"和prometheus.io/tcp-probe: "true"的service
- source_labels: [__meta_kubernetes_service_annotation_prometheus_io_scrape, __meta_kubernetes_service_annotation_prometheus_io_tcp_probe]
action: keep
regex: true;true
# 将原标签名__meta_kubernetes_service_name改成service_name
- source_labels: [__meta_kubernetes_service_name]
action: replace
regex: (.*)
target_label: service_name
# 将原标签名__meta_kubernetes_service_name改成service_name
- source_labels: [__meta_kubernetes_namespace]
action: replace
regex: (.*)
target_label: namespace
# 将instance改成 `clusterIP:port` 地址
- source_labels: [__meta_kubernetes_service_cluster_ip, __meta_kubernetes_service_annotation_prometheus_io_http_probe_port]
action: replace
regex: (.*);(.*)
target_label: __param_target
replacement: $1:$2
- source_labels: [__param_target]
target_label: instance
# 将__address__的值改成 `blackbox-exporter.monitor:9115`
- target_label: __address__
replacement: blackbox-exporter.monitor:9115
########## Ingress 监控配置 ##########
- job_name: 'blackbox-k8s-ingresses'
scrape_interval: 30s
scrape_timeout: 10s
metrics_path: /probe
params:
module: [http_get_2xx] # 使用定义的http模块
kubernetes_sd_configs:
- role: ingress # ingress 类型的服务发现
relabel_configs:
# 只有ingress的annotation中配置了 prometheus.io/http_probe=true 的才进行发现
- source_labels: [__meta_kubernetes_ingress_annotation_prometheus_io_http_probe]
action: keep
regex: true
- source_labels: [__meta_kubernetes_ingress_scheme,__address__,__meta_kubernetes_ingress_path]
regex: (.+);(.+);(.+)
replacement: ${1}://${2}${3}
target_label: __param_target
- target_label: __address__
replacement: blackbox-exporter.monitor:9115
- source_labels: [__param_target]
target_label: instance
- action: labelmap
regex: __meta_kubernetes_ingress_label_(.+)
- source_labels: [__meta_kubernetes_namespace]
target_label: kubernetes_namespace
- source_labels: [__meta_kubernetes_ingress_name]
target_label: kubernetes_name
########## 外部域名 监控配置 ##########
- job_name: "blackbox-external-website"
scrape_interval: 30s
scrape_timeout: 15s
metrics_path: /probe
params:
module: [http_get_2xx]
static_configs:
- targets:
- https://www.baidu.com # 改为公司对外服务的域名
- https://www.jd.com
relabel_configs:
- source_labels: [__address__]
target_label: __param_target
- source_labels: [__param_target]
target_label: instance
- target_label: __address__
replacement: blackbox-exporter.monitor:9115
########## 云上ECS 监控配置 ##########
- job_name: 'other-ECS'
static_configs:
- targets: ['101.201.68.158:9100']
labels:
hostname: 'test-node-exporter'
########## 进程 监控配置 ##########
- job_name: 'process-exporter'
static_configs:
- targets: ['<node-ip-2>:9256']
########## Mysql 监控配置 ##########
- job_name: 'mysql-exporter'
static_configs:
- targets: ['<node-ip-2>:9104']
########## Consul 监控配置 ##########
- job_name: consul
honor_labels: true
metrics_path: /metrics
scheme: http
consul_sd_configs: #基于consul服务发现的配置
- server: <node-ip-2>:18500 #consul的监听地址
services: [] #匹配consul中所有的service
relabel_configs: #relabel_configs下面都是重写标签相关配置
- source_labels: ['__meta_consul_tags'] #将__meta_consul_tags标签的至赋值给product
target_label: 'servername'
- source_labels: ['__meta_consul_dc'] #将__meta_consul_dc的值赋值给idc
target_label: 'idc'
- source_labels: ['__meta_consul_service']
regex: "consul" #匹配为"consul"的service
action: drop #执行的动作为删除
############ 指定告警规则文件路径位置 ###################
rule_files:
- /etc/prometheus/rules/*.rules
# 应用
[root@master01 7]# kaf prometheus-config.yaml
热重载 Prometheus 服务：
[root@master01 7]# curl -XPOST prometheus.example.com/-/reload
指标查询：
# 输入指标后，点击Excute
apisix_nginx_http_current_connections
三、使用 Grafana 绘制指标
prometheus 插件导出的指标可以在 Grafana 进行图形化绘制显示。
如果需要进行设置，请下载APISIX’s Grafana dashboard 元数据并导入到Grafana 中。
你可以到 Grafana 官方 下载 Grafana 元数据。
这里展示的模板ID为11719
四、Apisix webUI 大盘
浏览器输入http://apisix.example.com/，账号密码都为admin。点击【仪表板】-【现在配置】
填写grafana地址：http://grafana.example.com/d/bLlNuRLWz/apache-apisix后，点击【提交】
此时仪表板呈现空白界面
修改 grafana-config.yaml 文件：
[root@master01 7]# vim grafana-config.yaml
# 添加下面内容
[security]
allow_embedding = true
# 完整配置文件
[root@master01 7]# cat grafana-config.yaml
apiVersion: v1
kind: ConfigMap
metadata:
name: grafana-config
namespace: monitor
data:
grafana.ini: |
[server]
root_url = http://grafana.example.com
[smtp]
enabled = true
#企业邮箱使用smtp.exmail.qq.com:465，个人邮箱使用smtp.qq.com:465
host = smtp.qq.com:465
user = 1904763431@qq.com
password = xdjdwczivdfpcbhj
skip_verify = true
from_address = 1904763431@qq.com
[alerting]
enabled = true
execute_alerts = true
[security]
allow_embedding = true
重启 grafana
[root@master01 16]# kubectl rollout restart deploy grafana-core -n monitor
# 查看
[root@master01 7]# kgp -n monitor | grep grafana-core
grafana-core-54c48855c9-vvbp5 1/1 Running 0 11m
修改 apisix-dashboard configmap 文件：
[root@master01 16]# kubectl edit cm apisix-dashboard -ningress-apisix
apiVersion: v1
data:
conf.yaml: |-
conf:
listen:
host: 0.0.0.0
port: 9000
etcd:
prefix: "/apisix"
endpoints:
- apisix-etcd:2379
##增加如下部分
security:
access_control_allow_credentials: true # support using custom cors configration
access_control_allow_headers: "Authorization"
access_control-allow_methods: "*"
x_frame_options: "allow-from *"
content_security_policy: "frame-src *"
...
...
重启 apisix-dashboar：
[root@master01 16]# kubectl rollout restart deploy apisix-dashboard -ningress-apisix
# 查看
[root@master01 16]# kgp -ningress-apisix | grep apisix-dashboard
apisix-dashboard-5997fcf75-m6cnb 1/1 Running 0 2m18s
刷新后重新测试，观察到页面正常展示
其他异常情况如下
首页添加出现异常：
修复：https://github.com/apache/apisix-dashboard/issues/2586
修改 apisix-dashboard configmap 文件：
[root@master01 16]# kubectl edit cm apisix-dashboard -ningress-apisix
apiVersion: v1
data:
conf.yaml: |-
conf:
listen:
host: 0.0.0.0
port: 9000
etcd:
prefix: "/apisix"
endpoints:
- apisix-etcd:2379
##增加如下部分
security:
access_control_allow_credentials: true # support using custom cors configration
access_control_allow_headers: "Authorization"
access_control-allow_methods: "*"
x_frame_options: "allow-from *"
content_security_policy: "frame-src *"
...
...
重启 apisix-dashboar：
[root@master01 16]# kubectl rollout restart deploy apisix-dashboard -ningress-apisix
# 查看
[root@master01 16]# kgp -ningress-apisix | grep apisix-dashboard
apisix-dashboard-5997fcf75-m6cnb 1/1 Running 0 2m18s
测试验证：
五、Apache APISIX 中常见的指标（附加）
企业内部指标各有差异，以下是 Apache APISIX 中常见的一些关键的指标，为系统的监控和分析提供了丰富的信息。
HTTP 请求和响应指标
-
apisix_http_request_total ：记录了通过 APISIX 的 HTTP 请求总数。它可以用来观察系统的整 体流量。
-
apisix_http_request_duration_seconds ：HTTP 请求处理时间，有助于识别性能瓶颈。
-
apisix_http_request_size_bytes ：HTTP 请求的大小，可以分析请求的数据量。
-
apisix_http_response_size_bytes ：HTTP 响应的大小，用于监控响应数据量。
上游服务指标
-
apisix_upstream_latency ：上游服务的响应延迟。
-
apisix_upstream_health ：上游服务的健康状况。
系统性能指标
-
apisix_node_cpu_usage ：APISIX 节点的 CPU 使用率。
-
apisix_node_memory_usage ：内存使用情况。
流量指标
- apisix_bandwidth ：上行和下行的带宽使用情况。
错误和异常指标
- apisix_http_status_code ：HTTP 响应状态码的分布，特别是 4xx 和 5xx 错误，这对于识别潜 在的问题很重要。
其他特定场景
1、缓存指标（如果使用了缓存插件）：
-
缓存命中率
-
缓存大小
2、提供扩展插件指标：
- 根据配置的 APISIX 插件，可能会有特定的指标，如限流插件的拒绝请求数等。
Prometheus 告警示例
告警规则可以基于各种条件配置。例如，如果 apisix_http_request_duration_seconds 的平均值超 过预定阈值，Prometheus 可以配置为发送告警通知。
alerting:
alertmanagers:
- static_configs:
- targets:
- localhost:9093
rules:
- alert: HighRequestLatency
expr: avg_over_time(apisix_http_request_duration_seconds[2m]) > 0.5
for: 1m
labels:
severity: "critical"
annotations:
summary: "High request latency on APISIX"
虽然拥有更多且详尽的 Prometheus 指标可以增强监控和告警的维度，使之更加细致，但我们也必须认识到，这些指标的统计会消耗计算资源。更多的指标意味着更高的计算资源需求。同时，Prometheus在拉取这些指标时也会占用更多的带宽和时间。这可能对 API 网关或其他业务系统构成压力，极端情况下甚至可能影响业务请求的正常处理。因此，企业需要根据自己的业务需求和资源状况，寻找一个平衡点。
Apache APISIX 自从 3.0 版本起，对 Prometheus 插件进行了显著优化，引入了独立进程负责指标的统计和拉取工作。这一改进避免了因大量 Prometheus 指标统计而对业务流量产生影响的问题。
© 版权声明
文章版权归作者所有，未经允许请勿转载。
THE END
暂无评论内容
